- Top frame: Galvanized steel beam, 180mm width 5632-2 2688-2, 210*150*210 high-end galvanized corner pieces -4, purlin 40*80*1.2mm square pipe, insulation cotton 18 square, PE film, color steel leather plate, sealing the whole butyl tape waterproof, 831 ceiling tile 18 square
- Lower frame: Galvanized steel beam, 160mm wide roller beam 5632-2 2688-2, 210*150*160 high-end galvanized corner pieces -4, 9 50*100 square tubes
- Stand column: Galvanized strip steel 210*150*2525-4 pieces, equipped with connecting plates and 12*30 hex bolts (galvanized)
- Bottom: Flooding parts, 50mm/75mm optional
- Floor: Calcium silicate board *5 pieces (asbestos-free)
Product Overview:
Specifications:
| High-end packing box allocation order | ||
| 2.3 Real card *2990*6055*2896mm | ||
| standard | Product Name | constituent part |
| 1 | Top frame | Galvanized steel beam, 180mm width 5632-2 2688-2, 210*150*210 high-end galvanized corner pieces -4, purlin 40*80*1.2mm square pipe, insulation cotton 18 square, PE film, color steel leather plate, sealing the whole butyl tape waterproof, 831 ceiling tile 18 square |
| 2 | lower frame | Galvanized steel beam, 160mm wide roller beam 5632-2 2688-2, 210*150*160 high-end galvanized corner pieces -4, 9 50*100 square tubes |
| 3 | stand column | Galvanized strip steel 210*150*2525-4 pieces, equipped with connecting plates and 12*30 hex bolts (galvanized) |
| 4 | bottom | Flooding parts, 50mm/75mm optional |
| 5 | floor | Calcium silicate board *5 pieces (asbestos-free) |
| 6 | door | High-grade steel door (840*2035, flat sub-frame, European standard fire lock, 50/75 universal) |
| 7 | window | Plastic Steel Window B (insulating glass 3.0mm thick, with anti-theft net, screen window, 1130*1100mm, 2) 50/75 optional |
| 8 | wallboard | 1150,50mm single-sided laminated composite plate contains tray 0.35 80kg/m³ |
| 9 | downspout | ¢50mm,PVC downspout, 4 pieces |
| 10 | Ceiling closed edge | Ceiling with 4*4 831 ceiling tile homogeneous parts |
| 11 | Column Angle | Four negative Angle lines of the column contain negative Angle line fixings |
| 12 | ingredients | 995 structural glue 3.5 pieces, 4*20 round head drill tail wire 80, 12*75/12*100 hex drill tail wire 60, 12*100 hex drill tail wire 2, 12*75 hex drill tail wire 6, 12*25 hex drill tail wire 45, 4*25 self-tapping nails 32, 1 set of connecting bolts |
| 13 | ground | 1.6 Floor leather belt welds |
| 14 | power distribution | Brand electrical distribution, household 6㎡, 4m², 2.5m², 1.5㎡ copper wire (two cores of lamp wire) American standard socket Single open Two long strips of light An advanced eight-loop distribution box A 2P32A leakage protector Two 25A circuit breakers, one 10A circuit breaker An industrial socket plus an industrial socket cable box is welded to the top frame |
| 15 | Packing cabinet | Sandwich packing, wheel changing, container loading |
Modular Space Capsule House/Smart Eco Capsule
Apple Cabin House - Prefabricated Eco-Friendly Modular Housing
Apple Cabin House - Prefabricated Eco-Friendly Modular Housing
Apple Cabin House - Prefabricated Eco-Friendly Modular Housing
Xiaojiangcasa has a professional design and production team. The technical team strictly controls the product from research and development to implementation, insisting on starting from a professional perspective, innovatively developing future cabin products that are both aesthetically pleasing and practical, and implementing this concept in their work。
